Al2O3 Sapphire Crystal Substrate

Name: Al2O3 Sapphire Crystal Substrate
Brand: StonyLab
SKU: CS-Al2O3-C-1sp-5x5x0.5mm
Price: 9 USD
Availability: InStock

$9.99 USD

Sale Sold out

Shipping calculated at checkout.

Orientation C plane(0001) A plane(11-20)

Size 5x5x0.5mm 10x10x0.1mm 10x5x0.5mm

Polished 1 side polished 2 side polished

Product variants

Quantity

Processing: 5-15 business days. Shipping: 3-5 business days.

Purity: > 99.99%
Polished surface: substrate surface is EPI polished via a special CMP procedure with Ra < 5A, one or two side polished
Sapphire substrate is the popular substrates for III-V nitrides, superconductor and magnetic epi film due to less mis-matched lattice and stable chemical and physical properties
Orientation tolerance: +/-0.5°
