In-Situ Square Cabin Freeze Dryer, =-80°C Cold Trap, 0.2-2㎡ Drying Area, 3-30L, Silicone Oil Heating, 4-30kg/Batch Water Capture Capacity

Name: In-Situ Square Cabin Freeze Dryer, =-80°C Cold Trap, 0.2-2㎡ Drying Area, 3-30L, Silicone Oil Heating, 4-30kg/Batch Water Capture Capacity
Brand: StonyLab
SKU: SB-HX-LG-YWFC-20F-110V
Price: 30200.0 USD
Availability: InStock
Rating: 4.83 (18 reviews)

In-Situ Square Cabin Freeze Dryer, =-80°C Cold Trap, 0.2-2㎡ Drying Area, 3-30L, Silicone Oil Heating, 4-30kg/Batch Water Capture Capacity

$30,200.00 USD

Shipping calculated at checkout.

Capacity 3L 6L 15L 30L

Power Supply 110V/60HZ 220V/50HZ 380V/50HZ

Product variants

Quantity

About this item

Working Principle of the Freeze Dryer: By utilizing low-temperature freezing and vacuum drying technology, the moisture in the material sublimates directly from the solid state to the gas state, thereby achieving drying.
High Capacity & Efficiency: Features a 3L to 30 L capacity with a drying surface area from 0.2 square meters to 2 square meters, optimized for efficient freeze-drying.
Advanced Cold Trap: Equipped with a cold trap that reaches temperatures as low as -80 degrees Celsius, ensuring maximum moisture removal and preservation of sensitive materials.
Versatile Applications: Ideal for a wide range of fields including biomedical research, pharmaceutical manufacturing, chemical processing, food processing, and academic use.
Specialized for Biological Samples: Perfect for vacuum freeze-drying and preservation of most bacteria, actinomycetes, viruses, bacteriophages, rickettsia, molds, and yeasts. Note: not suitable for filamentous molds, fungi, algae, and protozoa.
Enhanced Drying Technology: Incorporates silicone oil heating to absorb heat during sublimation drying processes, reducing product temperature drop and speeding up the sublimation process to decrease drying time.

Processing: 7-10 business days.

Shipping: 7-15 business days.

1-Year Free Warranty

Rest easy knowing that all web registered members receive a 1 year of full coverage on all purchases, with additional protection options available for equipment.

Free Return

Enjoy 30-day free return on most regular orders. Check our Return Policy for full details and easy return steps.

Best Price Promise

Buy with confidence! Our 10-day Price Adjustment policy ensures you get the best deal.

Contact Us

support@stonylab.com

100% Satisfaction! Please feel free to contact us anytime. All your questions will be answered within timely manner.

Shipping Worldwide

Yes, StonyLab offers delivery service to customers worldwide! Free standard shipping on labware orders in the US.

View full details

Add To Cart

High-Throughput Experiment Tool

The machine can process multiple sample sets at once, with each tray's samples drying evenly without damp spots or cracking. For laboratories handling multiple research projects simultaneously, this machine greatly increases work efficiency. Previously, processing the same number of samples required several consecutive days, but now it can be completed in a single day, significantly improving overall team efficiency.

Silicone Oil Heating Accelerates Drying

The machine's silicone oil heating system ensures smooth temperature increases, preventing freeze cracking caused by rapid temperature drops. Combined with the ultra-low temperature cold trap, the moisture sublimation process is noticeably faster. Previously, freeze-drying protein samples took around 24 hours, but now it can be completed in approximately 16 hours, saving nearly one-third of the experimental time.

Outstanding Ultra-Low Temperature Cold Trap

The cold trap can reach -80 degrees Celsius, performing exceptionally well for freeze-drying sensitive proteins and viral samples. Previously, using ordinary freeze dryers often caused protein activity loss or crystallization, but with this machine, samples retain their original activity and structural integrity. Researchers are very satisfied, and experimental reproducibility has significantly improved.

Smooth Heating Process

The silicone oil heating ensures a smooth temperature increase without sudden changes that could damage or crack samples. The experiment safety has been significantly improved.

Laboratory Freeze-Drying Efficiency Greatly Improved

Since purchasing this square cabin freeze dryer, the efficiency of processing biological samples in our laboratory has increased significantly. Previously, freeze-drying 10 liters of samples required a full day, but now 20 liters can be completed in half a day, greatly saving experimental time. The cold trap temperature is very stable, moisture is thoroughly removed, and samples dry evenly. As a result, experimental outcomes are more reliable, and the pace of research has noticeably accelerated.
